Workflows

A B3OS workflow is a durable, versioned graph. It starts from a trigger, resolves inputs and expressions, executes nodes, persists node-level state, and exposes run history through the app, streams, and API.

Definition Shape

At a high level, a workflow definition contains:

Field	Purpose
nodes	Graph nodes for actions, logic, control flow, waits, loops, branches, and child workflows
inputSchema	Optional schema for manual, API, public, or template-driven inputs
props	Reusable workflow values referenced with {{$props.key}}
blockExpansions	Snapshots used when reusable blocks are expanded into a workflow
visibility	Controls whether a workflow is private, org-visible, publicly viewable, or publicly executable
publicWidgetConfig	Optional public widget presentation and execution settings

Node Model

Each node has a type, title, connector context, payload, output schema, and graph edges. Some nodes also define child collections such as loop bodies or branches.

Node area	Examples
Execution	Catalog action, built-in action, API call, webhook send, managed data query
Control flow	Branch, loop, delay, wait, child workflow
Data shaping	Format, regex, code transform, unit conversion, min/max, URL parsing
Context	Connector selection, wallet selection, input bindings, result schema, block context

Downstream expressions reference node IDs. Change display titles freely, but avoid changing IDs that are already used by published workflows or templates.

Lifecycle

Operation	What happens
Validate	Checks graph shape, required fields, schemas, connector requirements, and publish readiness
Publish	Creates or updates the live version used by automatic triggers
Pause	Stops automatic trigger execution while preserving the workflow
Resume	Re-enables automatic execution after review or remediation
Rollback	Restores a prior live version
Discard draft	Drops unpublished draft changes

Versioning

1. Draft edits do not affect the live version.
2. Publishing snapshots the draft into a live version.
3. Trigger listeners, schedules, public execution, and webhook URLs target the live version.
4. Rollback can restore a previous published version.
5. Run history remains attached to the version that produced it.

Visibility

Visibility	Behavior
private	Visible only to authorized organization users with workflow access
org	Visible inside the organization
public_view	Publicly viewable without allowing public execution
public_execute	Public execution is enabled through configured public surfaces

Runs and Executions

A run is one workflow invocation. Each node attempt is an execution.

Object	Useful fields
Run	Trigger source, input, status, timestamps, workflow version, failure summary, CU usage
Execution	Node ID, node type, status, input, output, error, start/end timestamps, retry/wait metadata

Run statuses include running, waiting, success, failure, and cancelled. Execution statuses include pending, running, success, failure, skipped, waiting, scheduled, cancelled, and auto_swapping.

Pause Reasons

Reason	Meaning
cu_exhausted	The organization does not have enough compute units for continued execution
disabled_action	A workflow depends on an action that is no longer executable
consecutive_failures	Repeated failures crossed the configured safety threshold

Review the latest failed runs, connector health, wallet funding, and action schema changes before resuming an automatically paused workflow.

Public and Embedded Execution

Public workflow surfaces can expose a workflow for viewing or execution. Public execution should be paired with narrow input schemas, rate limits, explicit visibility, and careful connector or wallet permissions.
